SOUND ABSORPTION
吸音模式 Sound Absorption:
Efficient and pro-environmen noise reduction sound absorption configuration - Danish ROCKFON rock wool. Double side and top surface of the box are covered with cloth finish + internal sound absorption module ,effective absorption of sound parallel transmission and uplink transmission, sgnificantly reduce external communication and protect privacy. At the same time, it also has the function of reducing the external noise to the person in the box, and Its physical properties can also separate the space, preventing the spread of sound, which is very important for the independent space.
高效、环保的降噪吸音配置- 丹麦ROCKFON岩棉。盒子内部双侧面及顶面都采用包布饰面+内部吸音模块,对声音平行传动及上行传动进行有效吸收,大幅降低止对外传播及保障隐私,同时也具备降低外部噪音对盒子里人员干扰,它的体量特性还可以起到空间分隔作用并阻挡声音扩散,这对独立空间非常重要。
特性 Characteristics:
·Clean environment: Volcanic rock is the high quality water purification material widely used in life.
·Pure inorganic materials, no organic matter, can not breed bacteria and other microorganisms.
·Raw materials are inexhaustible and resources are wasted.
·Product fire grade A1, ideal fireproofing material.
·Heat preservation and heat insulation.
·Sound absorption / sound insulation.
·洁净环保,火山岩是生活中广泛应用的优质水质净化材料。
·纯无机材料,不含有机质,不会滋生细菌等微生物。
·原料取之不尽,减少资源浪费。
·产品防火等级为A1级,理想的防火材料。
·保温节能。
·吸音/隔音。
吸音 Sound Absorption:
ROCKFON products NRC = 0.65 ~ 1.0 , Most products NRC≥0.9.
Sound has its own upward and parallel transmission. Sound absorption shows the ability to store sound waves on the surface of an object and convert them into an imperceptible form of heat. Sound absorption improves indoor sound by eliminating reflection of sound and reducing reverberation time. The sound absorption rate is usually expressed asαw ( weighted absorption coefficient ) or NRC ( noise reduction coefficient ). The value is 0 ~ 1, the higher the value, the better the sound absorption performance. The sound attenuation shows the ability to reduce the sound/noise transmission on the sound-absorbing module, and the well-attenuating sound-absorbing rock wool acts as a sound shield in one space or between another space.
ROCKFON产品NRC = 0.65 ~ 1.0 大部分产品NRC≥0.9。
声音是具有自身向上及平行传动性的。吸声显示出可以将声波储存在物体表面并将其转化为一种难以察觉的热能一种能力。吸声通过消除声音的反射和减少回响时间来改善室内声音。吸音率一般用αw(加权吸声系数) 或NRC(降噪系数)来表示,数值 为0 ~ 1,数值越高,吸音性能越好。 声音衰减显示了在吸音模块上减少声音/噪音传输的能力,具有良好衰减的吸音岩棉在一个空间里或和另一个空间之间扮演着声音屏蔽的角色。
环保 Environmental Protection:
ROCKFON rock wool board meets the strictest indoor air quality requirements, and some products also receive ISO5 or ISO4 clean grade. Rock wool does not contain organic matter and therefore does not support the growth of harmful microorganisms.
ROCKFON岩棉板符合最严格的室内空气质量要求,有些产品还获得了ISO5或ISO4洁净等级。岩棉还不含有机质,因此不会支持有害微生物的滋生。
CONFIGURATION
智能控制 Intelligent Control Module:
APP/ LCD screen control panel, qr code door opening, intelligent conference room and scene switching light control, Ventilation System control system and power supply control management, realize full intelligent space control and more scene functions.
APP/液晶控制面板,二维码开门,智能会议室及场景切换 灯光控制、新风控制及电源控制管理,实现空间全智能控制及更多场景功能。
灯光模块 Light Module:
Wall light/ceiling light adopts 24W German osram LED and control parts, color rendering index reaches 85RA, aluminum lamp body, up and down lighting design, effectively solve the use of light source under the light and the light source on the environment, no color difference, no strobe, slow light decline and other characteristics, effectively solve the light source and protect the eye clear.
壁灯/顶灯采用24W德国欧司朗LED及控制件,显色指数达到85RA,铝材灯体,上下照设计 ,有效解决下照使用光源及上照环境光源,无色差、无频闪、光衰慢等特点,有效解决光源及保护眼晴。
音响模块 sound moduler:
Intelligent Bluetooth sound system, remote control wireless connection, perfect support android/apple system, intelligent color sound system, high sound quality, professional dual channel frequency division processing, let work and life enjoy better sound quality.
智能蓝牙音响,远程遥控无线连接,完美支持安卓/苹果系统,智彩声学系统,高保音质,专业双通道分频处理,让工作及生活享受更好音质。
新风系统 Ventilation System:
The Ventilation System adopts the method of constant oxygen cleaning, super clean sound and micro positive pressure principle, continuously introducing fresh air into the outdoor, the fresh air volume reaches 100M3/H, and highly efficient purification through three filtration technologies, effectively removing harmful substances such as TVOC, formaldehyde, peculiar smell and PM2.5.Indoor air pressure is greater than outdoor air pressure, and exhaust gas is discharged through the door opening or air vent, forming a complete fresh air system to ensure air safety and cool air access.
新风系统采用恒氧洁净方式 ,超级净音,微正压原理,持续不断引入室外新鲜空气,新风量达到100m³/h,并通过3重过滤技术高效净化,有效去除TVOC、甲醛、异味及PM2.5等有害物质;室内气压大于室外,废气通过门缝或通气孔排出,形成完整新风系统,保障空气安全及冷气进入。
智能电视 Smart TV:
Wall-mounted integrated smart TV system + projector, 43-inch ultra LCD screen, support wifi wireless screen and fast file transfer, HDMI, USB, AV, NETWORK multi-interface design, dolby sound, AI system, so that multimedia applications everywhere.
挂墙式一体化智能电视系统+投屏器,43寸超高清液晶屏幕,支持wifi无线投屏及快速文件传输,HDMI\USB\AV\NETWORK多接口设计 ,杜比音效,AI系统,让多媒体应用无处不在。
MATERIAL More than 65% of materials can be recycled
Reinforced glassdoor/Surface plate
Aluminum frame
Steel plate
Cloth board
Carpet/glue flooring floor
强化玻璃门/表板 Reinforced glassdoor/ Surface plate :
Door and Surface plate board system use one side high grade reinforced glass, it has good function for permeability, and material has high fights impulse strength tall, cause harm not easily to human body, have good thermal stability more.
门及表板系采用单面优质强化玻璃,其具有良好的空间通透功能,并且材料抗冲击强度高,不易对人体造成伤害,更具有良好的热稳定性。
铝材 框架 Aluminum frame:
The frame is made of high-strength aluminum, and the structural strength can reach or exceed the characteristics of structural steel, which is of great help to the stability of the overall structure combination. And can greatly reduce the weight of the product.
框架采用高强度成型铝型材,结构强度则可达到或超过结构钢特性,对整体结构组合稳定性有很大的帮助。并且可以大大减轻产品重量。
钢制表板 Steel plate:
The steel plate is made of high quality steel with smoothness surface, and stable physical properties.
钢制表板采用优质冷轧钢板,表面平整度好,成型挂扣简便及精度高,并且材质物理性能稳定。
布板(内附钢板+吸音岩棉)表板 Cloth board (with steel plate + sound-absorbing rock wool) :
The surface is made of polyester fabric, which has high strength and elastic recovery ability, and is the most durable and heat-resistant fabric. Cloth surface can absorb sound effectively, the colour has very good decorate effect.
表板表面材制为涤纶布面,具有较高的强度与弹性恢复能力,耐用及耐热性最好的面料。布面能有效吸音,非富的色彩起到很好的装饰作用。
地毯/胶地板地面 Carpet/glue flooring floor:
The floor use finished carpets and meets the requirements of fireproof level. Carpet is soft, comfortable and safe, its can reduce noise effectively, heat insulation and decorate the space.The floor of the coffee house is made of finished PVC rubber, which is a good environmental protection material with soft texture, strong abrasion resistance, and effective waterproof and fireproof.
地面采用成品地毯,并且达到防火级别要求。地毯具有质地柔软、脚感舒适、使用安全的特点,其能有效减少噪声、隔热和空间装饰效果;咖啡屋地面采用成品PVC胶地板,其质地较软,耐磨程度强,并有效防水性防炎性,是很好的环保材料。
